Part Number / Product Name

BPC-6168

Brand: BOSER

Quantity

Product Information

BPC-6168 (BOSER)

Brand:

BOSER

Part Number/ Model Number:

BPC-6168

Lead Time:

AVAILABLE

Quantity in Stock:

AVAILABLE

Description

Boser BPC-6168 12.1" TFT 800 x 600 Panel PC

For Resellers and High Volume Orders:
Please request a quote to obtain preferred pricing.

Request Quote

Introduction

The BPC-6168 is an industrial-grade Panel PC that provides convinient expandability through three 32-bit PCI system slots. The rear design of BPC-6168 enhances the disassembly process when required. A single drive bay is available for one hard disk drive that can be easily installed before assembly. The BPC-6168 has a 12.1" display and an optional touch screen that operates under all types of working enviroment. It also comes with a reliable power supply and two 5cm ball bearing fans that enhance system stablity. The unit can also be mounted in several configurations. A variety of BOSER SBCs, ranging from 586 to Pentium III models, is compatible with the BPC-6168.

Features

12.1" TFT color panel display

Aluminum Chassis

Built-in C&T 69000 CRT/Panel display controller

Built-in Coppermine 800MHz CPU, 64MB SDRAM, HPS-4S Backplane, 250W Power Supply

Built-in HS-6237 Industrial Single Board Computer

Built-in Intel 82558 10/100 Based LAN

Provides 12.1" Touch Screen (optional)

Provides CompactFlash card reader (optional)

Provides DiskOnChip and supporting memory size of up to 288MB

Provides one 8cm cooling fan

Provides PC/104 Bus connector

Provides three expansion PCI slots

Provides two 3.5" and one 5.25" device spaces

Two COM ports, one USB
